Fanless Box PC

Intel® Processor N150 4-core processor up to 3.60 GHz
Intel Atom® x7433RE 4-core processor up to 3.40 GHz
Intel® Core™ 3 Processor N355 8-core processor up to 3.90 GHz

1 x DDR5-4800 SO-DIMM up to 16GB

Intel® Graphics

Auto reset for unresponsive system
(custom 1-255 sec/min delay settings in BIOS)

TPM 2.0

1 x M.2 3042/3052 Key B for WWAN w/ Nano SIM support
1 x M.2 2230 Key E for Wi-Fi/BT

DC 9-36V (nominal power input DC 12V/24V) via 2-pin terminal block

OCP, OVP, surge protection, reversed polarity protection

1 x 2.5” SATA SSD
1 x M.2 2242 Key B for SATA SSD
* M.2 Key B is a combo slot, either WWAN module or M.2 SATA can be installed.

Windows 11 IoT Enterprise LTSC
Ubuntu 24.04 LTS

2 x HDMI® up to 3840 x 2160 @ 60Hz as specified in HDMI 2.0b

1 x Line-out, 1 x Mic-in

2 x 2.5GbE (Intel I226-LM) via RJ-45

2 x USB 3.2 Gen 1
4 x USB 2.0

4 x DI (DC 5-36V)
4 x DO (DC 5V/100mA)

2 × RS-232/422/485
2 × RS-232 (Optional)

Aluminum Alloy

4 x SMA connector mounting hole

DIN rail, Wall, VESA mounting

1.2kg (2.64 lb)

150 x 106 x 55 mm (5.91 x 4.17 x 2.17 in.)

-40°C ~ 70°C (-40°F ~ 158°F) with 0.6 m/s airflow

-40°C ~ 80°C (-40°F ~ 176°F

10% RH ~ 90% RH (non-condensing)

CE, FCC Class A, UKCA, IEC/EN 62368-1

SBOX-2625-N150, SBOX-2625-N355, SBOX-2625-x7433RE

SBOX-2625-N150 : Intel® Processor N150 w/ 2x HDMI® / 2 x 2.5GbE / 6 x USB / 2 x COM / DC-IN 9-36V Embedded Computer
SBOX-2625-N355 : Intel® Core™ 3 Processor N355 w/ 2x HDMI® / 2 x 2.5GbE / 6 x USB / 2 x COM / DC-IN 9-36V Embedded Computer
SBOX-2625-x7433RE : Intel Atom® x7433RE w/ 2x HDMI® / 2 x 2.5GbE / 6 x USB / 2 x COM / DC-IN 9-36V Embedded Computer

Taiwan
