EMV800 FHD-N (Preliminary)
8 Channels 1080p Full HD Mobile DVR
System
Number of Channels |
8 CH |
---|---|
Video Compression |
H.264 / H.265 |
Audio Inputs |
8 |
Audio Outputs |
1 (RCA) |
Main Monitor |
VGA x 1 |
Call Monitor |
BNC x 1 / RCA x 1 |
Recording Resolution |
1080p / 720p / 960H / D1 |
Recording Mode |
Event, Normal + Event, Schedule |
Recording Rate NTSC |
30fps @ all resolutions |
Recording Rate PAL |
25fps @ all resolutions |
Pre Alarm Recording |
Supported |
Playback Mode |
Duplex |
Playback Search |
Time / Date, Event Search / Snapshot Search |
Alarm Inputs |
8 |
Alarm Outputs |
2 |
Video Loss Detection |
Supported |
Event Alarm |
Supported |
Ethernet |
1GbE x 2 (RJ-45 x 1, M12 x 1) |
WiFi |
Supported (Optional, M.2 Key-E 2230) |
4G / 5G |
Supported (Optional, M.2 Key-B 3052/3042) |
GPS |
Supported (Optional) |
HDD |
2.5" SSD x 1 (Max. 4TB) |
SD Card |
SD/SDHC Card (Max. 32 GB) – for alarm event backup recording only |
Interfaces |
RJ-45 x 1, RS-232 x 3, RS-485 x 1, USB x 3 |
GSensor |
3-Axis G-Sensor embedded |
System Control |
IR Remote Control, Mouse, Web UI |
PTZ Control |
Supported |
Power Source |
9-36 VDC |
Power Consumption |
20W / 60W (Heater On) |
Operating Temperature |
-40°C~55°C / -40°F~131°F |
Dimensions (W x D x H) |
229.6 x 218 x 63.4mm / 9.04" x 8.58" x 2.5" (With Anti-Vibration Bracket) |
Weight |
With Anti-Vibration Bracket: 2.6kg / 5.73lb |
Certificates |
CE, FCC, BSMI, EN50155, MIL-STD-810G (shock & vibration) |
Operating System |
Windows XP (32-bit) / Win7 (32 and 64-bit) |
CPU |
Intel Core I3-2100 |
RAM |
2GB |
LAN Speed |
10 / 100 / 1000 Mbps |
Web Browser |
IE11 and later, Firefox 50 and earlier, Chrome 44 and earlier, EF browser |
