Embedded u-blox NEO-M8U GPS with Untethered Dead Reckoning UDR & G-Sensor Mini PCIe Card

• u-blox 72-channel NEO-M8U UDR module including
• 3D inertial sensorsengine
• GNSS data is available in NMEA, UBX & RTCM protocols
• Max. 20Hz Navigation update rate
• Position accuracy 2m CEP

  • u-blox 72-channel NEO-M8U UDR module including 3D inertial sensorsengine
  • GNSS data is available in NMEA, UBX & RTCM protocols
  • Max. 20Hz Navigation update rate
  • Position accuracy 2m CEP
  • Temperature range: -40 to +85°C
  • Mini PCIe Signal Type USB2.0
  • Standard Full/Half-size Mini PCIe Card connect to computer easily

Receiver Type

Chipset NEO-M8U
Receiver Type GPS L1C/A, SBAS L1C/A, QZSS L1C/A, QZSS L1-SAIF, GLONASS L1OF, BeiDou B1I, Galileo E1B/C
Channels Supports 72 Channels
GNSS Center Frequency BeiDou : 1561.098 MHz, GPS : 1575.42 MHz, Glonass : 1602.5625

Sensitivity

  GPS & GLONASS GPS GLONASS Beidou Galileo
Tracking & Navigation -160dBm -160dBm -160dBm -160dBm -154dBm
Reacquisition -160dBm -159dBm -156dBm -155dBm -152dBm
Cold Start -148dBm -147dBm -145dBm -143dBm -133dBm
Hot Start -157dBm -156dBm -155dBm -155dBm -151dBm



Time to First Fix (TTFF)

  GPS & GLONASS GPS GLONASS Beidou Galileo
Cold Start 26Sec 30 Sec. 31 Sec. 39 Sec. 57 Sec.
Hot Start 1 Sec. 1 Sec. 1 Sec. 1 Sec. 1 Sec.
Aided Starts 3 Sec. 3 Sec. 3 Sec. 7 Sec. 7 Sec.

Accuracy

Horizontal Position
GPS&GLONASS GPS GLONASS Beidou Galileo
2.5m 2.5m 4m 3m TBC
Velocity Accuracy 0.5 m/s type
Heading Accuracy 1 degrees type
I/O 1 x Timepulse (connector type: 1 x 5pins pitch 1.27mm 90 degree)
1 x Battery Backup (connector type: 1 x 2pins pitch 1.27mm 180 degree)
Max Navigation 99% <60ns
Update Rate Typical : 1Hz Max. : 20Hz (Configurable)

Operational Limits

Dynamices <=4g
Altitude 50,000 m
Velocity 500 m/s

Output Message Format

GPS Protocol NMEA, UBX Binary, GGA, GLL, GSA, GSV, RMC, VTG, TXT

Multipath Suppression

Intelligent multipath detection and suppression

A-GPS

Supports AssistNow® Online and Offline, OMA SUPL Compliant

G-Sensor

3-axis accelerometer

Environmental Characteristics

Operating Temp. -40ºC to +85ºC
Storage Temp. -40ºC to +85ºC
Peak Supply Current Max=150mA
Max Performance Acquisition = 67mA
Eco Mode Tracking = 29mA
Power Input 3.3V +-10% VDC input
Dimensions 51 x 30 (mm)
