FARO CANBUS Module
ANTZER TECH’s FARO Series can optionally support protocols from RAW CAN 2.0 a/ b, OBDII, J1939 to J1708. With FARO’s VehicleON SDK, your system is allowed to get Car, Truck, Bus, Crane, Harvester & other commercial vehicle information easily.
- Full or Half PCI Express Mini Card
- Compliant with CAN 2.0 A/B Specification
- Equips 2-Channel Individual CAN and J1708 Interfaces
- CANbus Baud Rate Setting: 125/ 250/ 500/ 800/ 1000Kbps
- Vehicle Communication Protocols: OBD-II, J1939 and J1708
- Built-in Programmable CAN Identifier Filtering
- Sensor Integrated: 3D Gyroscope, 3D Accelerometer
- Support Linux Socket CAN Driver
- VehicleON and FleetON SDK for Quick System Integration
| Form Factor | Full or Half PCI Express Mini Card |
|---|---|
| Host Interface |
Standard: USB 2.0 via PCI Express Mini Card Socket Note: FARO-FS910 UART via PCI Express Mini Card Socket |
| Interface Number |
CAN (ISO 11898) x 2 Individual Channels J1708 x 1 (FARO-FS900/FS910 Only) |
| Sensor |
3D Gyroscope 3D Accelerometer |
| Protocol | OBD-II, J1939 and J1708 |
| Identifier filtering | Mask and Identifier List Mode |
| Driver Support |
Microsoft Windows 7 / 8.1 / 10 Linux Kernel 2.6 , 3.13, and 4.4 Socket CAN |
| SDK Support |
Microsoft Windows 7 / 8.1 / 10 Linux by Project |
| Operation Temp. | -40°C ~ 85°C |
| Vibration Test | Pass 7.69G@ 20~2000Hz, compliant with MIL-STD-810G category 24 |
| ESD Protection | 8kV Contact, 15kV air |
| Certificate | CE/FCC |
|
Dimension ( L x W x H ) |
Full PCI Express Mini Card: 50.9 x 30 x 6.56mm Half PCI Express Mini Card: 26.8 x 30 x 6.56mm |
